Silicone Rubber Heater with Thermostat for Water or Oil Drum Heating

Short Description:

Keep your industrial liquids flowing smoothly even in cold environments with our premium silicone rubber drum heater. Designed specifically for 55-gallon (200L) water and oil drums, this flexible heating solution delivers consistent, even temperature control to prevent viscosity thickening, freezing, and maintain optimal fluid properties for processing, storage, and transportation.

E-mail: kevin@yanyanjx.com

Product Detail

Product Tags

Product Overview

Our silicone rubber heater with integrated thermostat is engineered to solve the common problem of low-temperature fluid solidification and high viscosity in storage drums. Whether you're storing crude oil, cooking oil, hydraulic fluid, chemical solutions, or plain water, this heater fits snugly around the exterior of your drum to transfer heat directly to the contents, eliminating cold spots and reducing energy waste compared to internal heating systems.

Made from high-quality silicone rubber with embedded nickel-chromium heating wires, this heater combines flexibility, durability, and safety in one easy-to-install package. The built-in adjustable thermostat allows you to set and maintain your desired temperature automatically, so you don't have to monitor heating continuously. Perfect for industrial workshops, manufacturing facilities, food processing plants, oil depots, and outdoor storage sites.

Technical Specifications

Parameter	Specification
Applicable Drum Size	Standard 55 Gallon (200L) cylindrical drum
Heater Dimensions	1000mm x 250mm (39.4" x 9.8") (custom sizes available)
Power Rating	1000W / 1200W (optional)
Voltage	110V / 220V / 240V (optional)
Temperature Adjustment Range	0°C ~ 150°C (32°F ~ 302°F)
Temperature Control Accuracy	±5°C
Insulation Resistance	>500MΩ
Dielectric Strength	1500V/1min no breakdown
Protection Rating	IP54
Material	Fiberglass-reinforced silicone rubber, nickel-chromium heating wire

Main technical data

Color: red

Material: made of silicone rubber

Model: DR series

Power supply: AC or DC power supply

Voltage: Customized according to requirements

Application: Heating/keeping warm/anti fog/anti frost

Key Features

1.Uniform Heat Distribution

Equipped with a high-density heating element and multi-zone temperature regulation, the heating belt delivers consistent heat across the entire drum surface, eliminating cold spots and ensuring uniform material heating. This feature is critical for sensitive applications such as resin processing, oil warming, or adhesive production, where temperature fluctuations can compromise product quality.

2.Precise Temperature Control

Integrated with an intelligent thermostat (optional) or compatible with external temperature controllers, the heating belt offers precise temperature adjustment ranging fromambient +5°C to 250°C(customizable up to 300°C for high-temperature models). The digital display and user-friendly interface allow operators to set, monitor, and adjust temperatures with an accuracy of ±1°C, ensuring process stability and repeatability.

3.Flexible & Easy Installation

Crafted from a flexible, tear-resistant silicone rubber or fiberglass-reinforced material, the heating belt conforms seamlessly to drum contours (compatible with 20L, 50L, and custom drum sizes). It features adjustable straps with quick-release buckles or Velcro fasteners, enabling tool-free installation and secure attachment even during movement.

4.Energy Efficiency & Safety

Over-temperature protection (auto-shutdown at 180°C for standard models).
Short-circuit and earth leakage protection.
Flame-retardant outer layer (UL94 V-0 rated) and heat-resistant insulation (up to 300°C).
IP65/IP67 waterproof rating (optional), suitable for humid or dusty environments.

5.Durable & Long-Lasting Construction

Constructed with high-grade materials, including nickel-chromium (NiCr) heating wires, reinforced silicone, and stainless steel connectors, the heating belt withstands repeated use, mechanical stress, and exposure to chemicals (e.g., oils, solvents, and mild acids). T

Advantage

Customizable Solutions: Tailor wattage, size, temperature range, and connectors to your specific needs.
Cost-Effective: Reduces energy costs by 30% compared to traditional band heaters.
User-Friendly: Lightweight , portable, and easy to clean (wipe with a damp cloth).

Installation Instructions

1. Clean the outer surface of the drum to remove any dirt, oil, or debris that could prevent full contact between the heater and drum
2. Wrap the heater around the lower portion of the drum (generally 1/3 up from the bottom for optimal heat distribution) ensuring the heating side faces the drum surface
3. Secure the heater tightly to the drum using the included adjustable mounting straps, making sure there are no gaps between the heater and drum
4. Set your desired working temperature on the thermostat dial
5. Plug the power cord into a properly grounded outlet of the correct voltage, and the heater will automatically maintain your set temperature
For better energy efficiency and faster heat-up in very cold environments, we recommend adding an insulating blanket over the heater to reduce heat loss to the surrounding air.

Applications

Our silicone rubber drum heater is versatile enough for a wide range of commercial and industrial heating applications, including:
- Oil & Lubricant Storage:Maintain viscosity of heavy crude oil, engine oil, hydraulic fluid, and gear oil for easy pumping and processing
- Food & Beverage Industry:Prevent freezing and solidification of cooking oils, syrups, chocolate, and other temperature-sensitive food products in storage drums
- Chemical Processing:Keep liquid chemicals, resins, adhesives, and solvents at the correct temperature to prevent crystallization or thickening
- Outdoor Storage:Protect water drums from freezing in cold winter environments, preventing pipe blockages and drum damage
- Pharmaceutical Industry:Maintain consistent temperature for liquid pharmaceutical ingredients and bulk storage products
- Construction & Mining:Keep bitumen, asphalt, and other construction materials warm in cold weather for proper use
